120V 제품은 국내 사용 불가 합니다.

 (수출 건 , 대사관 등등 주문 시 발주 가능합니다.)

Max Configurable Power (Watts) : 700Watts / 1.0kVA

Output Voltage Distortion : Less than 5%

Output Frequency (sync to mains) : 50/60Hz +/- 3 Hz

Other Output Voltages :　110V , 125V

Topology : Line Interactive

Waveform type : Sine wave

Transfer Time : 6ms typical : 10ms maximum

Input

Input frequency : 50/60 Hz +/- 3 Hz (auto sensing)

Input voltage range for main operations : 82 - 144V

Input voltage adjustable range for mains operation : 75 - 154V

Number of Power Cords : 1

Other Input Voltages : 110V, 125V

Battery type :

Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Typical recharge time : 3hour(s)

Battery Charge Power (Watts) : 88Watts

Battery Volt-Amp-Hour Capacity : 264

Communications & Management

Interface Port(s) : SmartSlot, USB

Control panel : Multi-function LCD status and control console

Audible Alarm : Alarm when on battery : distinctive low battery alarm : configurable delays

Emergency Power Off (EPO) --

Available SmartSlot™ Interface Quantity : 1

Surge Protection and Filtering

Surge energy rating : 680Joules

Filtering :

Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

Maximum Height : 8.62inches (219MM, 21.9CM)

Maximum Width : 6.73inches (171MM, 17.1CM)

Maximum Depth : 17.28inches (439MM, 43.9CM)

Net Weight : 44.31lbs. (20.1KG)

Shipping weight : 49.91lbs. (22.64KG)

Shipping Height : 12.99inches (330MM, 33.0CM)

Shipping Width : 12.99inches (330MM, 33.0CM)

Shipping Depth : 23.23inches (590MM, 59.0CM)

Color : Black , Units per Pallet : 12.0

Environmental

Operating Temperature : 32 - 104 °F (0 - 40 °C)

Operating Relative Humidity : 0 - 95 %

Operating Elevation : 0-10000ft (0-3000meters)

Storage Temperature : -15 - 45 °C

Storage Relative Humidity : 0 - 95 %

Storage Elevation : 0-50000ft (0-15000meters)

Audible noise at 1 meter from surface of unit : 41.0dBA

Online thermal dissipation : 175.0BTU/hr

Conformance

Approvals :

CSA C22.2 No. 107.1, cULus, ENERGY STAR V2.0 (USA), FCC Part 15 Class A, ICES-003, UL 1778

Sustainable Offer Status

RoHS  : Compliant

Proposition 65 Warning : Available in Documentation tab

APC by Schneider Electric.

Smart-UPS and PowerChute are owned by Schneider Electric.
Industries S.A.S. or their affiliated companies.

All other trademarks are property of their respective owners.

In the interests of continuous product improvement all specifications are subject to change without notice.
